Hydrolux Pivot Shower Door 800mm with 800 x 800mm Raised Tray and Waste - 4mm

Important installation information: Please note, it's important to consider the minimum and maximum adjustment measurements. The enclosure doesn't sit flush to the side of a shower tray as this allows space for tiling.

Lightweight, polished aluminium frames

Made from polished aluminium, this enclosure blends perfectly with most bathroom colour schemes and is lightweight for faster and easier installation.

4mm thick safety glass

This enclosure uses thermally toughened 4mm safety glass. 4mm glass provides the best of both worlds: it's strong and sturdy enough for frequent use but light enough to function well on rollers or hinges.

1850mm shower door height

This shower enclosure has a height of 1850mm. This prevents water from splashing over the top and gives your shower a high-end look.

Stylish Easy-Grip door handles

The Hydrolux collection features Easy-Grip handles. Easy to fit and easy to grip with wet hands, these handles are a stunning finishing touch to your enclosure.

Quick & easy installation

These shower panels have been designed for quick and easy installation so that you can enjoy your new enclosure as soon as possible.

Reversible doors

These doors can be fitted to open left-to-right or right-to-left, giving you more options when planning your new bathroom.

Hydrolux Raised Shower Tray with Waste

Our shower trays are built with durability and performance in mind, with each one tested to support up to 4000kg, whether used with or without our own supplied riser leg kits. A typical 1200 x 800mm tray weighs just 18kg, making it significantly lighter than many stone resin options.

WRAS Approvals

In terms of standards and sustainability, our trays are fully compliant with all UK and EU requirements, including CE, EN 14527, EN 198, and REACH regulations. While WRAS certification isn’t required for trays, our acrylic sheet is manufactured to EN 263 for domestic use.

Flax Particle Board

Unlike some alternatives, we don’t use chipboard or other wood-based reinforcement materials – instead, we use Flax Particle Board, a more environmentally friendly alternative that offers strength without compromising on sustainability.

While it is possible to cut an acrylic capped tray, please note a cut edge can potentially be exposed to water ingress.

• Easy plumb shower tray with waste
• 60% lighter than stone resin trays
• Can be easily cut to size
• Universal shower enclosure compatibility
• Riser kit adds 95mm to the height of the tray
• 10 year guarantee for peace of mind

Hi-Flow Waste

• Standard 40mm connection
• A flow of 32 litres per minute
• A unique vented dome on the waste allows a high flow of water to pass through
• An inner unit allows a quick-release
• Also includes an offset elbow for ease of installation
• Size of waste: 90mm
• Chrome top
• Complies with BSEN1329/1:2000 and BSEN1451/1:2000 standards
